SYV同轴电缆50Ω、75Ω系列 |
||||||
| 产品编号 | 型号规格 | 内导体 | 绝缘外径mm |
编织网数编数 / 编丝线径MM |
护套外径 | 特性阻抗MΩ |
| 根数/直径 | ||||||
| CR-28-001 | SYV50-1 | 7/0.09 | 0.87±0.05 | 48x0.11 | 1.9±0.1 | 50±3.5 |
| CR-28-002 | SYV50-2-1 | 1/0.68 | 2.2±0.1 | 48x0.11 | 4.0±0.2 | 50±1.5 |
| CR-28-003 | SYV50-2-2 | 1/0.9 | 2.95±0.13 | 96x0.11 | 5.0±0.2 | 50±2.0 |
| CR-28-004 | SYV50-3-1 | 1/0.32 | 2.95±0.13 | 48x0.12 | 5.0±0.2 | 50±2.0 |
| CR-28-005 | SYV50-3-2 | 7/0.32 | 2.95±0.13 | 96x0.11 | 5.0±0.2 | 50±2.0 |
| CR-28-006 | SYV50-5-1 | 1/1.4 | 4.8±0.2 | 128Px0.11 | 7.2±0.3 | 50±2.0 |
| CR-28-007 | SYV50-7 | 7/0.75 | 7.25±0.25 | 144Px0.11 | 10.3±0.3 | 50±2.0 |
| CR-28-008 | SYV50-9 | 7/0.95 | 9.0±0.3 | 192Px0.11 | 12.2±0.4 | 50±2.0 |
| CR-28-009 | SYV50-12 | 7/1.15 | 11.5±0.3 | 48x0.17 | 15.0±0.4 | 50±3.13 |
| CR-28-013 | SYV75-2-1A | 1/0.26 | 1.6±0.1 | 48x0.11 | 2.9±0.2 | 70±5 |
| CR-28-014 | SYV75-2-1B | 1/0.34 | 2.0±0.1 | 48x0.11 | 3.3±0.2 | 70±5 |
| CR-28-015 | SYV75-3-1A | 1/0.48 | 3.0±0.13 | 64x0.11 | 5.0±0.25 | 70±3 |
| CR-28-016 | SYV75-3-2A | 7/0.17 | 3.0±0.13 | 64x0.11 | 5.0±0.25 | 70±3 |
| CR-28-017 | SYV75-3-1B | 1/0.48 | 3.0±0.13 | 96x0.11 | 5.0±0.25 | 70±3 |
| CR-28-018 | SYV75-3-2B | 7/0.17 | 3.0±0.13 | 96x0.11 | 6.0±0.2 | 70±3 |
| CR-28-019 | SYV75-4-1 | 1/0.6 | 3.7±0.13 | 96x0.11 | 6.0±0.2 | 70±3 |
| CR-28-020 | SYV75-4-2 | 7/0.21 | 3.7±0.13 | 96x0.11 | 6.0±0.2 | 70±3 |
| CR-28-021 | SYV75-5-1A | 1/0.75 | 4.8±0.2 | 64Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-022 | SYV75-5-2A | 7/0.26 | 4.8±0.2 | 64Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-023 | SYV75-5-1B | 1/0.75 | 4.8±0.2 | 96Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-024 | SYV75-5-2B | 7/0.26 | 4.8±0.2 | 96Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-025 | SYV75-5-1C | 1/0.75 | 4.8±0.2 | 128Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-026 | SYV75-5-2C | 7/0.26 | 4.8±0.2 | 128Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-027 | SYV75-5-1D | 1/0.75 | 4.8±0.2 | 144Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-028 | SYV75-5-2D | 7/0.26 | 4.8±0.2 | 144Px0.11 | 7.2±0.3 | 70±3 |
| CR-28-029 | SYV75-7-1 | 1/1.15 | 7.25±0.25 | 144Px0.11 | 10.3±0.3 | 70±3 |
| CR-28-030 | SYV75-7-2 | 7/0.4 | 7.25±0.25 | 144Px0.11 | 10.3±0.3 | 70±3 |
| CR-28-031 | SYV75-9 | 1/1.37 | 9.0±0.3 | 192Px0.11 | 12.2±0.4 | 70±3 |
